eneo - VM-SD8M
Available, delivery time: 2-3 days
8'' (20,3cm) LCD Monitor SD, 1024x768, LED, HDMI, VGA, Composite
read more
- Where else cheaper?
-
Ask? we would be happy to advise you!
+49 (0) 371 50 340 270
Product information "eneo - VM-SD8M"
Product availability information:
The item is ordered especially for you. The following is non-binding and subject to storage and delivery information from our suppliers:
- In stock: 6
- Expectation: 10+ in 3 weeks
- Replacement time: 14 weeks
- Last update: 17.02.2025 - subject to prior sale
Visualisierung & Storage - Monitore - 7'' - 19'' - eneo - VM-SD8M
8'' (20,3cm) LCD Monitor SD, 1024x768, LED, HDMI, VGA, Composite
Manufacturer datasheet
Hauptmerkmale
- Professioneller 8'' (20,3cm) LCD Monitor
- Für Dauerbetrieb ausgelegt 24x7x365 (Industrie Level)
- Maximale Auflösung 1024x768 Pixel
- LED Hintergrundbeleuchtung
- Kurze Reaktionszeit von 5ms
- Optimale Darstellung durch digitale 3D Filterung und Rauschunterdrückung
- Vielseitige Video Eingänge HDMI, VGA, Composite
- Lautsprecher integriert
- Betriebsspannung: 12VDC
- VESA Standard 75x75mm
- Metallgehäuse inklusive Standfuß
Specifications
| Dimensions (HxWxD) | 148,8x189,9x43mm |
| Applications | Industrie |
| Audio output | 1x 3,5mm jack |
| Audio inputs | 1 |
| Resolution pixels | 1024x768 |
| Viewing angle horizontal | 160 |
| Viewing angle vertical | 150 |
| Screen Size (cm) | 20,3 |
| Screen size | 8 |
| Housing color | black |
| Housing material | metal |
| Weight | 2.5 kg |
| Brightness typical | 250 |
| Backlighting | LED |
| Contrast ratio typical | 700:1 |
| Loudspeaker | 2 |
| Power consumption | 10W |
| Response time typical | 5 |
| Aspect ratio | 4:3 |
| Serial interfaces | no |
| Temperature range (operation) | -30°C ~ +85°C |
| Video outputs | Composite (CVBS) |
| Video inputs (type) | VGA |
| Applications | 24/7 |
| Temperature range (operation) | @ Humidity 10%-90% (non-condensing) |
| Video inputs (type) | HDMI |
| Video inputs (type) | composite (CVBS) |
| Video inputs (type) | 2x composite (CVBS) |
| Screen Size (cm) | 20.3 |
| Series | eneo Monitor |
| Viewing angle horizontal | 160° |
| Viewing angle vertical | 150° |
| Screen Size (cm) | 20.3 cm |
| Brightness typical | 250 cd/m² |
| Response time typical | 5 ms |
| Supply voltage | 12VDC |
| Manufacturers sheet | Download PDF-document |
Login
Specifications
| Dimensions (HxWxD) | 148,8x189,9x43mm |
| Applications | Industrie |
| Audio output | 1x 3,5mm jack |
| Audio inputs | 1 |
| Resolution pixels | 1024x768 |
| Viewing angle horizontal | 160 |
| Viewing angle vertical | 150 |
| Screen Size (cm) | 20,3 |
| Screen size | 8 |
| Housing color | black |
| Housing material | metal |
| Weight | 2.5 kg |
| Brightness typical | 250 |
| Backlighting | LED |
| Contrast ratio typical | 700:1 |
| Loudspeaker | 2 |
| Power consumption | 10W |
| Response time typical | 5 |
| Aspect ratio | 4:3 |
| Serial interfaces | no |
| Temperature range (operation) | -30°C ~ +85°C |
| Video outputs | Composite (CVBS) |
| Video inputs (type) | VGA |
| Applications | 24/7 |
| Temperature range (operation) | @ Humidity 10%-90% (non-condensing) |
| Video inputs (type) | HDMI |
| Video inputs (type) | composite (CVBS) |
| Video inputs (type) | 2x composite (CVBS) |
| Screen Size (cm) | 20.3 |
| Series | eneo Monitor |
| Viewing angle horizontal | 160° |
| Viewing angle vertical | 150° |
| Screen Size (cm) | 20.3 cm |
| Brightness typical | 250 cd/m² |
| Response time typical | 5 ms |
| Supply voltage | 12VDC |
| Manufacturers sheet | Download PDF-document |
