eneo - MPD-72M2713M0A
Delivery Time 2-3 weeks
1/2,8'' HD Dome, Fix, WDR, Tag/Nacht, 1920x1080, 12/24V, 2,7-13,5mm, Infrarot, IP67
read more
- Where else cheaper?
-
Ask? we would be happy to advise you!
+49 (0) 371 50 340 270
Product information "eneo - MPD-72M2713M0A"
Product availability information:
The item is ordered especially for you. The following is non-binding and subject to storage and delivery information from our suppliers:
- Discontinued line
- In stock: 0
- Expectation: 24 in 2 weeks
- Replacement time: 15 weeks
- Last update: 24.03.2025 - subject to prior sale
Kameratechnik - Analog HD-Kameras - Fix Domes - eneo - MPD-72M2713M0A
1/2,8'' HD Dome, Fix, WDR, Tag/Nacht, 1920x1080, 12/24V, 2,7-13,5mm, Infrarot, IP67
Manufacturer datasheet
Hauptmerkmale
- 1/2,8'' 2 Megapixel SONY STARVIS 2 CMOS-Sensor
- Hervorragende Leistung bei schwachem Licht
- Auflösung max. 1920x1080 Pixel (Full HD)
- Separate Ausgänge für Digital und Multisignal
- Multisignal: HD-TVI, AHD, CVI und Composite wählbar
- Digital Signal: EX-SDI, HD-SDI wählbar
- Motorisiertes Varifokal Objektiv 2,7-13,5mm
- ROI (Region of Interest) WDR Modus
- Integrierter Bewegungsmelder, Defog, Privatzonen
- IP67, Eingebaute Heizung, 3-Achsen-Aufhängering
- Wand- oder Deckeneinbaumontage
- Beschichtete Kuppel (Hard Coated), kratzfest
Specifications
| System | True Day&Night |
| Certificates | IK10 |
| Wide Dynamic Range (WDR) | WDR 113dB |
| Horizontal angle of view | 100 - 38 ° |
| Iris control | DC |
| Alarm outputs | no |
| Sensitivity | 0,08 Lux, at F1.4, 40IRE |
| Series | eneo KX-Series eneo Callisto |
| Illumination | infrared |
| Colour (bubble) | clear |
| Colour (housing) | Pantone Cool Gray 1C |
| Low speed shutter | yes |
| Zoom factor | 4x |
| Sensor size | 1/2.8'' |
| Heater | yes |
| Mounting | wall mount ceiling mount |
| Power consumption | 9.5W |
| Digital zoom | no |
| Housing | outdoor |
| Backlight compensation | BLC HLC |
| Video outputs | HD-TVI AHD CVI composite (CVBS) EX-SDI HD-SDI |
| Imager | CMOS |
| Focal length | 2,8 - 12 mm |
| Protection rating | IP67 |
| Housing material | aluminium |
| MOD (Minimum object distance) | 0,5 m |
| Alarm inputs | no |
| Digital Noise Reduction (DNR) | yes |
| Lens type | Varifocal (motorized) |
| Sensitivity | at F1.4 40IRE |
| IR cut filter | switchable |
| Temperature range (operation) | -30°C ~ +50°C |
| Vandalism resistant | yes |
| Motion detector | yes |
| Supply voltage | 12VDC 24VAC |
| Vertical angle of view | 53 - 19 ° |
| Resolution pixels | 1920x1080 1280x720 720x576 |
| Dimensions (HxWxD) | 119x140mm |
| Analysis functions | Defog |
| Resolution pixels | 1920x1080 |
| Illumination range | approx. 50m |
| Frame rate | 25/30fps @ 1920x1080p |
| Horizontal angle of view | 100 - 38° |
| Vertical angle of view | 53 - 19° |
| Aperture range (F) | F1.4 |
| Rotation range | +/-173 |
| Backlight compensation | BLC |
| Weight | 1kg |
| Camera type | Dome |
| Sensitivity | 0,08 Lux |
| Sensitivity | at F1.4 |
| Mounting | wall mount |
| Series | eneo KX-Series |
| Signal format | Composite (FBAS) |
| Serial interfaces | Coaxitron (HD Protocol) |
| Supply voltage | 12VDC |
| Day&Night switch | ICR |
| Video outputs | HD-TVI |
| Resolution pixels | 1280x720 |
| Frame rate | 50/60fps @ 1280x720p |
| Backlight compensation | HLC |
| Sensitivity | 40IRE |
| Mounting | ceiling mount |
| Series | eneo Callisto |
| Signal format | HD-TVI @ 2MP |
| Supply voltage | 24VAC |
| Video outputs | AHD |
| Resolution pixels | 720x576 |
| Signal format | AHD @ 2MP |
| Video outputs | CVI |
| Signal format | CVI @ 2MP |
| Video outputs | composite (CVBS) |
| Signal format | EX-SDI (270 Mbps) |
| Video outputs | EX-SDI |
| Signal format | HD-SDI (1.485 Gbps) |
| Video outputs | HD-SDI |
| Focal length | 2,7 - 13,5 mm |
| Rotation range | +/-173° |
| Lichtempfindlichkeit | 0,08 Lux at F1,4, 40 IRE |
| Lichtempfindlichkeit | 0,08 Lux at F1,4, 40 IRE |
| Successor | 243651 |
| Manufacturers sheet | Download PDF-document |
