eneo - MPC-54A0003M0A
Delivery Time 2-3 weeks
1/2,9'' HD Kamera 2560x1440, Tag/Nacht, AF Zoom, WDR, 3,2-9 mm, Innen
read more
- Where else cheaper?
-
Ask? we would be happy to advise you!
+49 (0) 371 50 340 270
Product information "eneo - MPC-54A0003M0A"
Product availability information:
The item is ordered especially for you. The following is non-binding and subject to storage and delivery information from our suppliers:
- In stock: 0
- Expectation: 24 in 2 weeks
- Replacement time: 15 weeks
- Last update: 24.03.2025 - subject to prior sale
Kameratechnik - Analog HD-Kameras - Zoomkameras - eneo - MPC-54A0003M0A
1/2,9'' HD Kamera 2560x1440, Tag/Nacht, AF Zoom, WDR, 3,2-9 mm, Innen
Manufacturer datasheet
Hauptmerkmale
- 1/2,9'' 6,64 Megapixel SONY STARVIS CMOS-Sensor
- Auflösung max. 2560x1440@25/30fps
- Optisch 3x Auto Fokus Zoom, 3,2~9mm
- Separate Ausgänge für Digital und Multisignal
- Multisignal: HD-TVI, AHD wählbar
- Digital Signal: EX-SDI, HD-SDI wählbar
- DOL-WDR 3 Fach Scan der Bilder @25/30fps &
- ROI (Region of Interest) WDR Modus
- Point of Interest und Smart Motion Zoom
- Kompakte Bauform
Specifications
| System | True Day&Night |
| Wide Dynamic Range (WDR) | DOL-WDR 120dB D-WDR WDR 113dB |
| Horizontal angle of view | 78 - 6 ° |
| Iris control | DC |
| Alarm outputs | no |
| Sensitivity | 0,1 Lux, at F1.6, 40IRE |
| Series | eneo KX-Series eneo Candid Box |
| Colour (housing) | Pantone Cool Gray 1C |
| Low speed shutter | yes |
| Zoom factor | 3x |
| Sensor size | 1/2.9'' |
| Blower | no |
| Power consumption | 6W |
| Housing | indoor |
| Digital zoom | yes |
| Backlight compensation | BLC HLC |
| Imager | CMOS |
| Video outputs | HD-TVI AHD EX-SDI HD-SDI |
| Focal length | 3,2 - 9 mm |
| Housing material | aluminium |
| MOD (Minimum object distance) | 0,5 m |
| Alarm inputs | no |
| Digital Noise Reduction (DNR) | yes |
| Lens type | auto focus zoom |
| Sensitivity | at F1.6 40IRE |
| IR cut filter | switchable |
| Temperature range (operation) | -10°C ~ +50°C |
| Vandalism resistant | no |
| Motion detector | yes |
| Supply voltage | 12VDC |
| Vertical angle of view | 42 - 3 ° |
| Resolution pixels | 2560x1440 1920x1080 1280x720 |
| Dimensions (HxWxD) | 73.5x72x89mm |
| Analysis functions | Defog |
| Resolution pixels | 2560x1440 |
| Frame rate | 25/30fps @ 2560x1440p |
| Horizontal angle of view | 75 - 26° |
| Vertical angle of view | 41 - 15° |
| Aperture range (F) | F1.6 |
| Backlight compensation | BLC |
| Weight | 300g |
| Camera type | Zoom Camera |
| Sensitivity | 0,1 Lux |
| Sensitivity | at F1.6 |
| Series | eneo KX-Series |
| Signal format | HD-TVI @ 4MP |
| Serial interfaces | Coaxitron (HD Protocol) |
| Day&Night switch | ICR |
| Video outputs | HD-TVI |
| Wide Dynamic Range (WDR) | DOL-WDR 120dB |
| Analysis functions | Digital Image Stabilization |
| Resolution pixels | 1920x1080 |
| Frame rate | 25/30fps @ 1920x1080p |
| Backlight compensation | HLC |
| Sensitivity | 40IRE |
| Series | eneo COAXIZE |
| Signal format | AHD @ 4MP |
| Video outputs | AHD |
| Wide Dynamic Range (WDR) | D-WDR |
| Resolution pixels | 1280x720 |
| Frame rate | 50/60fps @ 1280x720p |
| Series | eneo Candid Box |
| Signal format | EX-SDI @ 4MP |
| Video outputs | EX-SDI |
| Wide Dynamic Range (WDR) | WDR 113dB |
| Signal format | HD-SDI (1.485 Gbps) |
| Video outputs | HD-SDI |
| Supply voltage | 24VAC |
| Serial interfaces | RS-485 |
| Lichtempfindlichkeit | 0,1 Lux at F1,6, 40 IRE |
| Frame rate | 25/30fps @ 1280x720p |
| Lichtempfindlichkeit | 0,1 Lux at F1,6, 40 IRE |
| Manufacturers sheet | Download PDF-document |
