eneo - MED-62V2713M0A
Available, delivery time: 2-3 days
1/2,8'' HD Dome, Fix, Tag/Nacht 1920x1080, Objektiv 2,7-13,5mm IR LED, 12VDC, IP66
read more
- Where else cheaper?
-
Ask? we would be happy to advise you!
+49 (0) 371 50 340 270
Product information "eneo - MED-62V2713M0A"
Product availability information:
The item is ordered especially for you. The following is non-binding and subject to storage and delivery information from our suppliers:
- In stock: 29
- Expectation: 25 in 6 weeks
- Replacement time: 15 weeks
- Last update: 24.03.2025 - subject to prior sale
Kameratechnik - Analog HD-Kameras - Fix Domes - eneo - MED-62V2713M0A
1/2,8'' HD Dome, Fix, Tag/Nacht 1920x1080, Objektiv 2,7-13,5mm IR LED, 12VDC, IP66
Manufacturer datasheet
Hauptmerkmale
- 1/2,8'' 2.3 Megapixel Progressive Scan CMOS-Sensor
- Kompaktes Metallgehäuse für Außenanwendung
- Auflösung max. 1920x1080 (Full HD)
- Multisignal: HD-TVI, AHD, CVI und Composite wählbar
- Varifokal 2,8~12mm Tag/Nacht Objektiv
- LSC (Objektiv Shading Korrektur)
- Schwenkbarer IR-Sperrfilter
- RS-485 Steuer-Ein-Ausgang
- 3D-DNR Noise Reduction,
- Digital Wide Dynamic Range (D-WDR)
- Integrierter Bewegungsmelder
- Kratzfeste beschichtete Kuppel
Specifications
| Dimensions (HxWxD) | 108x144,4mm |
| Alarm outputs | no |
| Alarm inputs | no |
| Analysis functions | Defog |
| Resolution pixels | 1920x1080 |
| Resolution pixels | 960x576 |
| Imager | CMOS |
| Illumination | infrared |
| Illumination range | approx. 30m |
| Motion detector | yes |
| Frame rate | 25/30fps @ 1920x1080p |
| Horizontal angle of view | 95 - 27° |
| Vertical angle of view | 49 - 15° |
| Aperture range (F) | F1,3 |
| Iris control | DC |
| Focal length | 2,7 - 13,5 mm |
| Sensor size | 1/2.8'' |
| Digital zoom | no |
| Digital Noise Reduction (DNR) | yes |
| Colour (housing) | Pantone Cool Gray 1C |
| Colour (bubble) | clear |
| Backlight compensation | BLC |
| Housing | outdoor |
| Housing material | aluminium |
| Weight | 1.0kg |
| Heater | no |
| Camera type | Dome |
| Power consumption | 6W |
| Sensitivity | 0,3 Lux |
| Sensitivity | at F1.3 |
| Low speed shutter | yes |
| Blower | no |
| MOD (Minimum object distance) | 0,5 m |
| Mounting | wall mount |
| Lens type | Varifocal |
| Protection rating | IP66 |
| Series | eneo KX-Series |
| Signal format | Composite (FBAS) |
| Serial interfaces | Coaxitron (HD Protocol) |
| Supply voltage | 12VDC |
| System | True Day&Night |
| Day&Night switch | ICR |
| Temperature range (operation) | -20°C ~ +50°C |
| Vandalism resistant | yes |
| Video outputs | HD-TVI |
| Wide Dynamic Range (WDR) | D-WDR |
| Certificates | IK10 |
| Zoom factor | 4x |
| Backlight compensation | HLC |
| Sensitivity | 40IRE |
| Mounting | ceiling mount |
| Signal format | HD-TVI @ 2MP |
| Video outputs | AHD |
| Signal format | AHD @ 2MP |
| Video outputs | CVI |
| Signal format | CVI @ 2MP |
| Video outputs | composite (CVBS) |
| Lichtempfindlichkeit | 0,3 Lux at F1,3, 40 IRE |
| Lichtempfindlichkeit | 0,3 Lux at F1,3, 40 IRE |
| Manufacturers sheet | Download PDF-document |
