eneo - MCB-68M2713M0A
Available, delivery time: 2-3 days
1/2,8'' HD Kamera, Tag/Nacht, 3840x2160, Infrarot, WDR, 2,7-13,5mm, 12/24V, IP67
read more
- Where else cheaper?
-
Ask? we would be happy to advise you!
+49 (0) 371 50 340 270
Product information "eneo - MCB-68M2713M0A"
Product availability information:
The item is ordered especially for you. The following is non-binding and subject to storage and delivery information from our suppliers:
- In stock: 20+
- Expectation: 20+ in 2 weeks
- Replacement time: 15 weeks
- Last update: 24.03.2025 - subject to prior sale
Kameratechnik - Analog HD-Kameras - Bullet - eneo - MCB-68M2713M0A
1/2,8'' HD Kamera, Tag/Nacht, 3840x2160, Infrarot, WDR, 2,7-13,5mm, 12/24V, IP67
Manufacturer datasheet
Hauptmerkmale
- 1/2,8'' 8,64 Megapixel SONY STARVIS CMOS-Sensor
- Auflösung max. 3840x2160@15/12,5fps
- Motorisiertes Varifocal Objektiv 2,7~13,5mm
- Separate Ausgänge für Digital und Multisignal
- Multisignal: HD-TVI, AHD wählbar, Composite SUB
- Digital Signal: EX-SDI, HD-SDI wählbar
- DOL-WDR 3 Fach Scan der Bilder @25/30fps &
- ROI (Region of Interest) WDR Modus
- DIS (Digital Image Stabilization) Funktion
- Integrierte Anschlussbox
- Einfache und aufgeräumte Verkabelung
- IR Beleuchtung (4 x SMD High Power LED's)
Specifications
| Dimensions (HxWxD) | 130,5x82,1x265,1mm |
| Alarm outputs | no |
| Alarm inputs | no |
| Analysis functions | Defog |
| Resolution pixels | 3840x2160 |
| Imager | CMOS |
| Illumination | infrared |
| Illumination range | approx. 40m |
| Motion detector | yes |
| Frame rate | 12,5/15fps @ 3640x2160p |
| Horizontal angle of view | 105 - 45° |
| Vertical angle of view | 59 - 25° |
| Aperture range (F) | F1.6 |
| Iris control | DC |
| Focal length | 2,7 - 13,5 mm |
| Sensor size | 1/2.8'' |
| Digital zoom | yes |
| Digital Noise Reduction (DNR) | yes |
| Colour (housing) | Pantone Cool Gray 1C |
| Backlight compensation | BLC |
| Housing | outdoor |
| Housing material | aluminium |
| Weight | 1.25kg |
| Camera type | Bullet |
| Power consumption | 11.5W |
| Sensitivity | 0,06 Lux |
| Sensitivity | at F1.6 |
| Low speed shutter | yes |
| MOD (Minimum object distance) | 0,5 m |
| Mounting | wall mount |
| Lens type | Varifocal (motorized) |
| Window heater | no |
| Protection rating | IP67 |
| Series | eneo KX-Series |
| Signal format | Composite (FBAS) |
| Serial interfaces | Coaxitron (HD Protocol) |
| Supply voltage | 12VDC |
| System | True Day&Night |
| Day&Night switch | ICR |
| Temperature range (operation) | -50°C ~ +50°C |
| Vandalism resistant | no |
| Video outputs | HD-TVI |
| Wide Dynamic Range (WDR) | DOL-WDR 120dB |
| Zoom factor | 5x |
| Analysis functions | Digital Image Stabilization |
| Resolution pixels | 2560x1440 |
| Frame rate | 25/30fps @ 2560x1440p |
| Backlight compensation | HLC |
| Sensitivity | 40IRE |
| Mounting | ceiling mount |
| Series | eneo COAXIZE |
| Signal format | HD-TVI @ 8MP |
| Supply voltage | 24VAC |
| Video outputs | AHD |
| Wide Dynamic Range (WDR) | D-WDR |
| Resolution pixels | 1920x1080 |
| Frame rate | 25/30fps @ 1920x1080p |
| Series | eneo Candid Small |
| Signal format | AHD @ 8MP |
| Video outputs | CVI |
| Signal format | CVI @ 8MP |
| Video outputs | composite (CVBS) |
| Signal format | EX-SDI @ 8MP |
| Video outputs | EX-SDI |
| Signal format | HD-SDI (1.485 Gbps) |
| Video outputs | HD-SDI |
| Video outputs | composite (CVBS) SUB |
| Dimensions (HxWxD) | 130,50x82,15x265,80mm |
| Lichtempfindlichkeit | 0,06 Lux at F1,6, 40 IRE |
| Lichtempfindlichkeit | 0,06 Lux at F1,6, 40 IRE |
| Manufacturers sheet | Download PDF-document |
